Description

  • Active 3-way nearfield reference monitor with ATL™ bass loading
  • Frequency response: 25Hz - 25kHz (- 3dB @1m full space, on-axis)
  • Max. cont. SPL: 113dB @1m (half space value calculated as +3dB from full space measurement.
  • Unweighted input, 20-20kHz Pink Noise (IEC) with 12dB CF for 2 hours AES2-1984 duration)
  • State-of-the-art Class-D amplifiers: HF 400W, MF 400W, LF 2x 400W
  • Analogue / AES3 digital input (16/24-bit, 18 -192kHz sample rate)
  • Digital ‘through’ output (AES3 24-bit 96kHz
  • SoundAlign™ network control interface for single or group EQ & settings
  • Sophisticated DSP crossover, driver protection, EQ, and delay/polarity options
  • PMC8-2 + PMC8-2 SUB creates PMC8-2 XBD, with up to 6dB of additional headroom
  • Optional dedicated floor stands for PMC8-2 (40”) and PMC8-2 XBD (19”)
PMC Pro PMC 8-2 Active Monitors Specifications
Type Active 3-way nearfield reference monitor with ATL™ bass loading
Drive Unit Complement LF: 2 × PMC 200mm (8”) studio 8 drivers
MF: PMC 55mm (2”) soft dome mid-range
HF: PMC 27mm (1”) soft dome tweeter
Effective ATL™ Length 3m (9.8 ft)
Frequency Response 25Hz - 25kHz (-3dB) (@1m full space, on-axis)
Sensitivity +4 dBu input signal = 98 dB SPL @ 1m
Max Continuous SPL 113 dB @ 1m
Max Peak SPL 125 dB @ 1m
Directivity H ±45 degrees
V ±50 degrees (-6dB off axis @10kHz)
Input XLR switchable between analogue & digital AES3
Analogue Input +20 / +24 dBu max. input level (selectable)
22K ohm input impedance
Digital Input 16/24-bit AES3 signal (left, right or left + right)
18 - 192 kHz sample rate
110 ohm input impedance
Expansion Card Slot For future connectivity upgrades
Output XLR digital AES3 (fixed 24-bit @ 96kHz)
Network RJ45 (PMC SoundAlign web interface)
Latency 2.4 mS
Amplifier Power per Channel LF: 2 × 400W RMS
MF: 1 × 400W RMS
HF: 1 × 400W RMS
Mains 100 - 240 VAC auto-switching, 50-60Hz (IEC C14)
Power Consumption (Idle) 50 W
Power Consumption (Max) 1500 W
Dimensions (H × W × D) 534mm (21”)
551mm (21.7”)
440mm (17.3”)
Weight 39 kg (86 lbs) each
